Taiwan type H-8056Taiwan type
Semi-automatic Column Typa Band Saw H-7050N
|
Model |
H-8056 |
|
|
Capacity |
● |
560 mm (22") |
|
■ |
800 x 560 mm (28" W x 22" H) min. clamp with 75 mm (3") |
|
|
Blade Speed |
20 to 80 m/min. (65 to 264 fpm) (INVERTER) |
|
|
Motor |
Blade Drive |
7.5 kw (10HP) |
|
Hyd. Pump |
2.2 kw (3HP) |
|
|
Coolant Pump |
0.2 kw (1/4HP) |
|
|
Blade Size |
6800 x 54 x 1.6 mm (267" x 2.1" x 0.063") |
|
|
Blade Tension |
Hydraulic |
|
|
Index Length |
300 mm (11.8") |
|
|
Machine Weight |
4200 kg (9240 lb) |
|
|
Floor Space (L x W) |
3700 x 2200 mm (145.6" x 86.6") |
|
